*Notes:
*Deck width=160mm: Park the scooter at the coordinate frame and measure its LWH. Unit: mm, reserve the integer. The scooter conforms to the requirements of product specification and the deviation is ≤±2%. Data from Brightway’s Lab.
*20km range: In the endurance mileage test, apply a load of 75 ± 5kg to the scooter. On a flat road, start the test with an ambient temperature of (25 ± 5) ℃ and a wind speed of ≤ 3km/h. Drive at an average speed of 15km/h until the scooter speed decreases significantly and cannot be driven again. When the matching adapter indicator turns green, TIRT tests the data with the battery fully charged. Report No.OTA1-20230190.
*The rated power of 300W motor: the max. voltage is 42Vdc, the motor is loaded to the max. current and the motor input power is tested through a power meter. Data tested by TIRT. Report No.OTA1-20230190.
*Climbing performance 14%: As tested by TIRT, the scooter can ride stably on the slope when climbing to a distance of 10m from slope bottom at a constant speed of 15km/h with a battery of 70±10% and a load of 75±5kg. There’s no speed loss or power interruption during the climbing test. The speed when leaving slope should be over 6km/h. Report No. OTA1-20230190.
*Max. speed of 25km/h: As tested by TIRT, the Xiaomi Electric Scooter 4 Lite is accelerated in the auxiliary driving zone and runs at max. speed in test zone, with total load 75±5kg, battery capacity of 70%±10%, room temperature of (25±5)℃ and average wind speed of ≤3km/h. The top speed in test zone is measured respectively through the tachometer or Bluetooth and display. Report No. OTA1-20230190.
*Walking mode: 6km/h. Standard mode: 20km/h. Sport mode: 25km/h. Total load: 75±5kg. Battery capacity: 70%±10%. The Xiaomi Electric Scooter 4 Lite has accelerated driving in auxiliary driving zone at the room temperature (25±5)℃ and meanwhile wind speed ≤3m/s. Its top speed is maintained in the test zone. The top speed in test zone is measured respectively through the tachometer or Bluetooth and display. Data from Brightway's Lab.
